Ultralift TP Magnetic Lifter
Designed for safe and efficient thin plate lifting
Ultralift LM
Safe, efficient, magnetic lifter for moving steel loads
- Supplied with a range of safety features
- Simple, quick, single face engagement with the load
- Can be used for flat or round section steel stock
- Facilitates more lifts per hour
- Reduced risk of load damage
Overview - Ultralift LM
Ultralift LM
Ultralift LM is a cost-effective lifting magnet that provides fast and efficient lifting for flat and round section steel. Ultralift LM uses high-intensity neodymium 'rare earth' magnet material for the highest power to weight ratio.
The material is permanently magnetic, and switching the Ultralift LM on and off is manual, no power is required and it has no operating costs. It can be used anywhere - just hook it to your hoist or crane. Ultralift LM comes complete with a safety button that locks the handle in place and prevents accidental release of the load.
Technical Data
Model Variations
| Product Number | Self Weight | Material Length Max | Flat Section SWL | Flat Section Thickness Min | Round Section SWL | Round Section Diameter Max |
|---|---|---|---|---|---|---|
| LM0275 | 9.9lbs | 60" | 275lbs | 0.8" | 110lbs | 10 |
| LM0550 | 18.7lbs | 60" | 550lbs | 1.0" | 220lbs | 12" |
| LM1100 | 38.5lbs | 80" | 1100lbs | 1.2" | 440lbs | 16" |
